A low attenuation surface wave transmission line system for launching surface waves on a bare and unconditioned conductor, such as are found in abundance in the power transmission lines of the existing power grids. The conductors within the power grid typically lack dielectric and special conditioning. Accordingly, the present invention includes a first launcher, preferably including a mode converter and an adapter, for receiving an incident wave of electromagnetic energy and propagating a surface wave longitudinally on the power lines. The system includes at least one other launcher, and more likely a number of other launchers, spaced apart from one another along the constellation of transmission lines. The system and associated electric fields along any given conductor are radially and longitudinally symmetrical.

A lightweight, efficient, microwave power transmitting antenna is disclosed, suitable for use in a space borne transmitter for beaming solar generated electrical power down to earth based receiving antennas. The space borne antenna structure is formed by modules that are structurally integrated into a multimodule antenna array. Each module comprises a rectangular framework of limited depth having rigid sides circumscribing a generally open region in which a plurality of spaced parallel single wire Goubau transmission lines are strung to create a "see-through" harp-like configuration. A Klystron powered feed wave guide is disposed as one structural side of the module for exciting standing electromagnetic waves on the plurality of Goubau lines. Printed circuit Yagi endfire radiators are supported on dielectric webs disposed in juxtaposition with the Goubau lines for being synchronously excited by the standing waves on such lines. The modular, open framework construction together with the use of single wire Goubau transmission lines for exciting the web mounted Yagi radiators, forms an exceptionally lightweight structure which when disassembled can be consolidated in a high density package for being launched into orbit, and then subsequently assembled in space.

A low attenuation surface wave transmission line system for launching surface waves on a bare and unconditioned conductor, such as are found in abundance in the power transmission lines of the existing power grids. The conductors within the power grid typically lack dielectric and special conditioning. Accordingly, the present invention includes a first launcher, preferably including a mode converter and an adapter, for receiving an incident wave of electromagnetic energy and propagating a surface wave longitudinally on the power lines. The system includes at least one other launcher, and more likely a number of other launchers, spaced apart from one another along the constellation of transmission lines. The system and associated electric fields along any given conductor are radially and longitudinally symmetrical.
